RayPlex Mouse Inflammation Bead Array 1
  • 商城价格 登录后可查看价格
  • 货号 FAM-INF-1-48
  • 品牌 Raybiotech/瑞博奥 ( 一级代理 )
  • CAS号
  • 规格/包装 48 tests
  • 单位 盒
  • 储存条件 4℃
  • 现货状态 现货
  • 数量

    - +

    成功收藏产品
  • 立即购买
登录后可见商家信息
热门推荐
商家描述 商家资质信息 产品评价(0)
Size 48 tests
Species Mouse
Quantitative/Semi-Quantitative Quantitative
Number of Targets Detected 13
Compatible Sample Types Cell Culture Supernatants, Serum
Solid Support Fluorescent Microbeads
Method Of Detection Flow Cytometry
Design Principle Sandwich-based
Research Area Inflammation
Estimated Lead Time 1-2 business days
Shipping Type Blue ice
Storage 4°C


  • Less sample, more data: up to 25 proteins can be quantified from only 25 µl or less of your precious sample
  • 4 hour processing time
  • 5-10x more cost-effective than ELISA
  • Compatible with most flow cytometers
  • No specialized or dedicated instrument(s) needed
  • High specificity and system reproducibility
  • Well-suited for high throughput assays

Target Names


GCSF, IFN-gamma ,IL-10, IL-12 p70 ,IL-17A,IL-1 beta(IL-1 F2), IL-2, IL-23 p19, IL-4, IL-6,KC(CXCL1) ,MCP-(CCL2), TNF alpha

Application Notes

Suggested Application
Multiplexed Protein Detection; Biomarker Screening; Identifying Key Factors; Confirming Biological Process; Biomarker Validation; Validation of Antibody Array Results; Quantitative Protein Detection; Establishing Normal Range
Kit Components
  • RayPlex™ Multiplex Bead Cocktail
  • 1X Assay Diluent
  • 20X Wash Buffer
  • Lyophilized Protein Standard Mix
  • Biotinylated Detection Antibody Cocktail
  • 10X PE Conjugate
  • Flow Cytometer Setup Bead Cocktail
  • V-bottom 96-well Microplate
  • Filter 96-well Microplate
  • RayBio® Serum Diluent
Other Materials Required
  • Orbital 96-well plate shaker (with ability to reach 1000 rpm)
  • Flow cytometer with blue and red lasers capable of measuring phycoerythrin (PE) and allophycocyanin (APC) channels
  • Aluminum foil or 96-well Plate Aluminum Sealers
  • Distilled water
  • 1.5 ml polypropylene microcentrifuge tubes or similar
  • Microcentrifuge
  • If using the Filter 96-Well Microplate (Item 11): Vacuum manifold compatible with a 96-well microplate
  • Optional: 96-well round bottom plate (to prepare samples)
  • Optional: High throughput sampler (HTS) for 96-well plate reading

Don't have a compatible flow cytometer? RayBiotech provides full testing services for RayPlex™ bead arrays. Get a quote!

Protocol Outline
  1. Prepare Reagents, Standards, and Samples
  2. Add RayPlex™ Multiplex Bead Cocktail to each well
  3. Incubate with Samples and Standards
  4. Incubate with Biotinylated Detection Antibody Cocktail
  5. Incubate with Streptavidin-Conjugated Fluorophore
  6. Analyze with a compatible flow cytometer
  7. Perform data analysis

Storage/Stability

Upon receipt, all components should be stored at 4°C. The Lyophilized Protein Standard Mix (Item 4) should be stored at 4°C or below. Use reagents immediately after preparation. If stored at the proper temperature, the kit will retain complete activity for at least 6 months.
